Features：
* Galvanically separated contacts
* Screw terminals with self-lifting clamps for easy wiring
* Positive Opening of NC contacts
* 4 x 90° actuator positions
* Horizontal or Vertical Operation
Operating Speed: 0.05mm-0.5m/sec
Operating Frequency: Mechanical:120ops/min Electrical: 30ops/min
Insulation Resistance: >100MΩ @ 500V DC
Rated Current/Voltage: 10A/600V AC (EN60947-5-1)
Electrical Rating: UL/cUL Listed(E216958) for AC15 A600/ DC13 Q300
Service Life: Mechanically 10,000,000, Electrically 500,000
Operating Temperature: -25~80℃(-13~176°F) without formation of ice
Degree of protection: IP65/IP67
| Varumärke | SUNS |
|---|---|
| Leverantör | SUNS Electric Co.,Ltd. |
Inget datablad tillgängligt för denna produkt.
